Designed as a specialist optical device, Hiphotonics' Polarization preserving WDM 1x2 (PMWDM) lets two distinct wavelengths of light travel through it preserving their polarization states. This product is a useful addition in the field of optical telecommunications and engineering since it presents various special qualities and uses.
PMWDM98CS Series | Min | Max | Unit | |
Pass Channel Wavelength Range | 1520 1610 | nm | ||
Reflection Channel Wavelength Range | 965 995 | nm | ||
Insertion Loss* | Pass Channel | 1.0 | dB | |
Reflect Channel | 0.6 | dB | ||
Polarization Dependent Loss (PDL) | 0.1 | dB | ||
Polarization Mode Dispersion (PMD) | 0.05 | ps | ||
Passband Ripple | 0.2 | dB | ||
Insertion | Pass Channel | 18 | dB | |
Reflect Channel | 30 | dB | ||
Return Loss | 50 | dB | ||
Directivity | 50 | dB | ||
Operating Power | 500 | mW | ||
Operating Temperature | 0 to~+70 | ℃ | ||
Storage Temperature | -40 to~+85 | ℃ | ||
Fiber Type | Port 1&3 | Corning Flexcore 1060 | ||
Port 2 | Corning SMF-28 | |||
Package Dimensions | 250Um Bare Fiber | P1¢5.5x34.0 | mm | |
900Um loose tube | P2¢5.5x40.0 | mm |
First, PMWDM is meant to preserve the input signal's polarization state, hence removing polarization mode dispersion. This special ability guarantees that the signal quality stays the same even across several optical components in the network. This helps to lower distortion and mistakes and preserve the integrity of the signal.
Second, PMWDM is extensively applied in fiber-optic communication systems, where it helps to effectively transmit signals over great distances. It also finds use in optical fiber sensor systems, whereby it multiplexes various sensing channels onto a single optical fiber.
Every month our specialist workshop can generate a lot of PMWDM units. This helps us to guarantee quick delivery times and readily handle tailored orders. Furthermore, every one of our items is tested extensively for dependability to guarantee they operate as intended and provide improved performance.
At last, PMWDM is safe for air travel, which makes it the best option for worldwide clients looking for premium optical components. We promise outstanding quality for our products; therefore, reading our comprehensive product specs will help our clients to better appreciate the powers of our PMWDM.
Polarity Maintaining Highly specialized optical device WDM 1x2 (PMWDM) presents various particular qualities and uses. Our specialist workshop can produce a lot of PMWDM units, therefore enabling us to provide high-quality goods that satisfy consumer needs.
