Micro Wavelength Division Multiplexer High iso

0755-27662758

sales@hiphotonics.com

Modern technology with great advantages in many different uses is High-isolation Micro Wavelength Division Multiplexer (WDM). Perfect for usage in telecommunications, fiber optic networks, and other high-speed data transmission systems, this device lets signals be sent in both bi-directional and uni-directional WDM systems.


HMWDM13CS Series Min Max Unit
Pass Channel Wavelength Range Type 1315 1260 1360 nm
Type 1513 1460 1620 nm
Reflection Channel Wavelength Range Type 1315 1460 1620 nm
Type 1513 1260 1360 nm
Insertion Loss* Pass Channel 0.7 dB
Reflect Channel 0.5 dB
Polarization Dependent Loss (PDL) 0.10 dB
Polarization Mode Dispersion (PMD) 0.05 ps
Passband Ripple 0.30 dB
Insertion Pass Channel 35 dB
Reflect Channel 22   dB
Return Loss 50 dB
Directivity 50 dB
Operating Power 500 mW
Operating Temperature 0 to~+70
Storage Temperature -40 to~+85
Fiber Type Port 1&3 Corning SMF-28
Package Dimensions 250Um Bare Fiber P1¢5.5x34.0 mm
900Um loose tube P2¢5.5x40.0 mm


High-isolation Micro WDM's broad operational wavelength range is one of its main benefits since it lets it effectively broadcast light signals over several wavelengths. The gadget also includes a system monitoring tool to keep an eye on data flow, thereby guaranteeing seamless operation of systems.
High-isolation Micro WDM's small scale is another important advantage since it facilitates simple integration into current systems. Applications requiring limited space, such laboratory settings, especially benefit from this.

The gadget also boasts ultra-low polarization and polarization mode dispersion as well as low insertion loss, therefore reducing the signal loss during data transmission. Furthermore guaranteeing stable and effective signal transmissions are strong-isolation Micro WDM's strong channel isolation and epoxy-free optical path.

Professional seminars allow for adjustable specifications and quick delivery times, thereby enabling significant monthly output quantities in terms of manufacturing capacity. It has passed many environmental and green plan compliance tests and is rather dependable.

Product specs and dependability testing findings for individuals in the market for High-isolation Micro WDM are easily accessible and strictly adhering to airline transportation standards helps. In general, this gadget offers in many uses best performance, dependability, and efficiency.
