Coarse Wavelength Division Multiplexer151413

0755-27662758

sales@hiphotonics.com

An essential part of every cellular or telecommunications network is the coarse wavelength division multiplexer, or CWDM. Using it, numerous optical wavelengths can be coupled or separated across a single optical fibre. This technology's adaptability to changing network needs and low price point have contributed to its meteoric rise in popularity.


MWDM15CS Series

Min

Typical Max Unit
Pass Channel Wavelength Range 1540~1560 nm
Reflection Channel Wavelength Range 1480~1500 nm
Reflection Channel Wavelength Range 1260~1360 nm
Insertion Loss* Pass Channel 0.9 1.1 dB
Reflect Channel 0.9 1.1 dB
Polarization Dependent Loss (PDL) 0.20 dB
Polarization Mode Dispersion (PMD) 0.20 ps
Passband Ripple 0.20 dB
Insertion Add/Drop@ ≥50 dB
Express@ ≥45 dB
Return Loss ≥50 dB
Directivity ≥50 dB
Operating Power 500 Mw
Operating Temperature -10 to~+70
Storage Temperature -40 to~+85
Fiber Type Corning SMF-28
Package Dimensions 250Um Bare Fiber P1¢5.5x34.0 mm
900Um loose tube P2¢5.5x40.0 mm


Our company develops CWDM 1x2 devices that are environmentally friendly and comply with green goals. We monitor our manufacturing process closely to ensure compliance with rules and efficient energy consumption. Our CWDM devices offer ultra-low insertion losses, making them perfect for narrow down distribution and cellular applications. They also demonstrate extraordinary thermal stability and work well in severe situations.

Reliability and compatibility with fibre optical amplifiers are two hallmarks of our CWDM devices. With our expert workshop, we can crank out a tonne of merchandise every month. In order to cater to each client's unique requirements, we provide individualised solutions. We promise top performance even in the most trying environments, and we put our goods through extensive reliability testing.

Apart from telecommunication, our CWDM devices find use in the medical, military, and government sectors among other areas. Our technique of speedy delivery guarantees that our customers get their products right away. Every one of our goods is subject to extensive quality control inspections, thus we promise their efficiency and performance.


Our goods are air transportation certified, hence we make sure they are properly packed to be protected during shipment. Our company is dedicated to provide our customers with premium CWDM devices that guarantee best performance and greatest value. To satisfy changing needs of our clients, we aim to always enhance our goods and services.
